Operational Temperature Minus 20 to Plus 80 Degrees Strain Gauges Utilizing Epoxy Carrier Material for Performance in Harsh Environments

Product Description:

The Foil Strain Gauge is a highly precise and reliable micro pressure sensor designed to deliver exceptional performance in various industrial and scientific applications. Engineered with advanced technology, this product offers superior accuracy and durability, making it an ideal choice for measuring strain in different materials and structures. Among the range of strain measurement devices, this foil strain gauge stands out due to its impressive features and customizable options, catering to specific user requirements.

One of the key highlights of this foil strain gauge is its classification as a micro pressure sensor. This feature allows it to detect minute changes in pressure and strain with remarkable sensitivity, providing users with highly accurate data essential for quality control, structural monitoring, and experimental research. The micro pressure sensor capability ensures that even the smallest deformation or stress in a material can be precisely measured, enabling engineers and researchers to make informed decisions based on reliable information.

In addition to its high sensitivity, the foil strain gauge boasts excellent stability characterized by minimal creep and hysteresis. The creep value of this product is maintained at ±0.05% Full Scale, which means it exhibits negligible drift over time even when subjected to prolonged loads. This low creep rate ensures that the strain measurements remain consistent and trustworthy during long-term monitoring. Similarly, the hysteresis is also limited to ±0.05% Full Scale, indicating that the gauge provides repeatable and accurate readings without significant deviation when the load is cycled. These characteristics are crucial for applications requiring precise strain data over extended periods and under varying load conditions.

Another significant advantage of this foil strain gauge is its wide working temperature range, spanning from -20℃ to +80℃. This broad temperature tolerance enables the sensor to operate effectively in diverse environmental conditions, whether in cold storage facilities or moderately heated industrial settings. The ability to maintain performance across such a temperature range makes it versatile and suitable for use in automotive, aerospace, civil engineering, and manufacturing sectors, where temperature fluctuations are common.

The product also offers customized service options, allowing users to tailor the strain gauge according to their specific needs. Customization can include modifications in size, resistance, grid pattern, and carrier material to better fit unique applications. This flexibility ensures that the foil strain gauge can be seamlessly integrated into various measurement systems, enhancing its usability and effectiveness. By providing customized solutions, the manufacturer supports a wide array of projects, from small-scale laboratory experiments to large-scale industrial installations.

This foil strain gauge belongs to the family of Linear Strain Gauges, which are widely recognized for their capability to measure linear deformation accurately. Linear Strain Gauges are essential tools in structural health monitoring and material testing, where understanding the extent of elongation or compression is critical. By utilizing a full bridge strain gauge configuration, this product amplifies the output signal, thereby increasing sensitivity and accuracy. The Full Bridge Strain Gauge setup involves four active gauge elements arranged in a Wheatstone bridge circuit, which not only enhances the measurement resolution but also compensates for temperature variations and other environmental factors.

Strain Gauges, including this foil strain gauge, are fundamental components in modern engineering and research. They provide invaluable data that help in predicting material behavior, preventing structural failures, and optimizing design. The high precision, stability, and adaptability of this foil strain gauge make it an excellent choice for professionals seeking reliable and efficient strain measurement solutions.

In summary, the Foil Strain Gauge is a micro pressure sensor that combines low creep and hysteresis values (both ±0.05% Full Scale), a wide operating temperature range (-20℃ to +80℃), and customizable service options to meet diverse application requirements. As a member of the Linear Strain Gauges family and utilizing a Full Bridge Strain Gauge configuration, it ensures accurate, stable, and repeatable strain measurements. This makes it an indispensable tool for engineers, researchers, and technicians who demand the highest quality in strain sensing technology.

Features:

• Product Name: Foil Strain Gauge
• Working Temperature Range: －20～＋80℃
• Operational Temperature: －20～＋80℃
• Measurement Range: 0-1000 Microstrain
• Creep: ±0.05% Full Scale
• Usage: Load Cell Sensor and Tension Measuring
• Available in Full Bridge Strain Gauge and Half Bridge Strain Gauges configurations
• High accuracy and reliability for precise strain measurement
• Suitable for various strain gauges applications

Technical Parameters:

Applications:

The Foil Strain Gauges from Top Sensor, specifically the BF-350 series and HA Series models, are engineered to deliver precise and reliable strain measurements across a wide range of applications. Originating from China, these high-quality Full Bridge Strain Gauges are designed to operate efficiently within a working temperature range of －20～＋80℃, making them suitable for use in various environmental conditions.

The Foil Strain Gauges are ideal for applications requiring accurate measurement of minute deformations, with a measurement range of 0-1000 microstrain and an impressively low hysteresis of ±0.05% Full Scale. Such specifications ensure that these Full Bridge Strain Gauges are perfect for structural health monitoring in civil engineering projects, such as bridges, buildings, and dams, where detecting subtle strain changes is critical for safety and longevity.

In the manufacturing sector, the BF-350 series Foil Strain Gauges are widely used for stress analysis in automotive components, aerospace structures, and machinery parts. Their full bridge configuration enhances signal output and temperature compensation, providing engineers with precise data to optimize design and performance. The gauges’ robust design and customizable service options make them suitable for integration into various testing and monitoring systems.

The Foil Strain Gauges also find application in research and development laboratories where material testing and mechanical analysis require high accuracy and consistency. Their customizable features ensure that customers can tailor the gauges to fit specific project requirements, enhancing experimental precision and reliability.

Top Sensor’s supply ability of 10,000pcs each week, combined with a minimum order quantity of 50pcs and a delivery time of just 3 weeks, allows for efficient procurement to meet both small and large-scale project demands. Payment terms require T.T 100% in advance, ensuring smooth transaction and delivery processes.

Overall, the Top Sensor Full Bridge Strain Gauge BF-350 series and HA Series provide exceptional performance for various application occasions and scenarios, including structural monitoring, automotive and aerospace testing, industrial machinery analysis, and scientific research, making them a trusted choice for professionals seeking superior strain measurement solutions.
